Model
YM-MH4000，YM-MH5000

Review

Description

Description
H Beam Gantry Welding Machine
H Beam Gantry Welding Machine

1.MH series gantry type welding machine is a special equipment for H-beam welding.

2.Welding trolley is controlled and driven by inverter with stable speed, digital display speed and good reliability.

3.Three axes Mechanical tracking arc guide mechanism and left right rotation floating tracking are equipped to ensure the welding torch aligned with weld seam.

4.The welding operation adopts integrated linkage control, which is convenient and reliable.

5.The arc guide device has double direction, back and forth welding characteristics to eliminate return time and improve work efficiency.

FEATURES
H Beam Gantry Welding Machine

Easy Operate

H Beam Gantry Welding Machine

Precise Positioning

H Beam Gantry Welding Machine

Recovery System

VEDIO
PARAMETERS

Item

Parameter

Model

YM-MH4000

YM-MH5000

Flange width

200-800mm

200-800mm

Web height

200-1500mm

200-1800mm

Rail distance

4000mm

5000mm

Welding position

Fillet welding in the downhand/ flat position

Fillet welding in the downhand/ flat position

Driver

Bilateral

Bilateral

Rails length

18000mm(Customer supply)

18000mm(Customer supply)

Power

12.7KW(It does not include welding power source)

12.7KW(It does not include welding power source)
PRODUCT ADVANTAGES
Quality Assurance
Adopts gantry structure , the materials are solid, and the service life is long
Cost Reduction and Efficiency Increase
And it has the function of automatic feeding and recycling ,which not only reduces loss, but also minimizes the loss of flux, and truly realizes cost reduction and efficiency increase
High Pass Rate
Equipped with a welding torch fine-tuning device and a mechanical tracking mechanism to ensure the precise position of welding torch, effectively improve welding accuracy and stability, and improve the qualified rate of finished products.
Easy to Operate
When  welding arm is adjusted in a large range, the lifting mechanism of welding arm and the horizontal movement mechanism of welding arm can be manipulated, and the operation is flexible and convenient.
